The MEC-LAN-2001i is a single isolated GbE LAN module designed for embedded PCs. It adheres to the M.2 standard, compatible with PCI Express x1 and the M.2 form factor. This module fits into any host computer with M.2 slots and provides a cost-effective way to expand your computer's Gigabit network.
Top Performance: The MEC-LAN-2001i features one Ethernet port with auto-negotiation for 10/100/1000Mbps connections and IEEE 802.3x flow control. It utilizes the Intel I210-IT Gigabit Ethernet Controller for high performance, efficiency, and stability.
High Usability: The MEC-LAN-2001i is versatile, including a daughter board, bracket, and connection cable in the standard package to support various applications.
MECFIX – Versatile Mounting: MECFIX is a unique mounting mechanism designed specifically for MEC daughter boards. It offers the following mounting options:
1.    Standard PCI/PCIe Bracket
2.    Low Profile PCI/PCIe Bracket
3.    Internal Mounting within the PC system at any position and angle
4.    Customizable Front/Rear Plate for PC systems based on the MEC daughter board dimensions

Features

•    Single-Lane (x1) PCI-Express with data rates up to 5.0/2.5Gbps
•    Fully adheres to PCI-Express Base Specification Rev. 2.0
•    Integrated 10/100/1000Mbps transceiver
•    Supports IEEE 802.3x Full-Duplex flow control
•    Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3z standards
•    Meets EN61000-4-2 (ESD) with Air-15kV and Contact-8kV protection
•    Meets EN61000-4-4 (EFT) with 2kV protection
•    Complies with EN61000-4-5 with 2kV Surge protection


Specifications

Download MEC-LAN-2001i specifications [EN, .pdf]
